TOA Ceiling Mount Speaker ZS-2360-AS
Detail Produk
| Merek | TOA |
| Tipe | ZS-2360-AS |
| Deskripsi Produk | The ZS-2360-AS Ceiling Mount Speaker is ideal for use in a voice alarm system or BGM system. It easy mounting to the ceiling. The input impedance can be easily changed by changing the tap position of transformer. Spesifikasi Teknis: Rated Noise Power : 6 W (100 V Line), 3 W (70 V Line) | Rated Impedance ; 100 V line: 1.7 kΩ (6 W), 3.3 kΩ (3 W), 6.7 kΩ (1.5 W), 13 kΩ (0.8 W) ; 70 V line: 1.7 kΩ (3 W), 3.3 kΩ (1.5 W), 6.7 kΩ (0.8 W), 13 kΩ (0.4 W) | Sensitivity : 94 dB (1 W, 1 m) (330 Hz - 3.3 kHz, pink noise) | Frequency Response : 45 Hz - 20 kHz (pink noise -20dB) | Speaker Component : 16 cm (6") cone-type | Dimensions for Fixing Hole ; Mounting hole : φ200 ±3mm ; Ceiling thickness 5-25 mm (0.2"-0.98") | Speaker Mounting Method : Suspension Spring | Applicable Cable ; Solid wire: φ0.5 - φ3.0 mm2 (AWG20-12) | Connection : Push wire connection (bridging terminal 2-branch type) | Finish ; Frame: Steel plate, white (RAL 9016 equivalent), paint ; Grille: Steel net, white (RAL 9016 equivalent), paint | Dimensions : φ200 × 5 (exposed section) + 71 (D) mm (φ7.87" × 0.19" + 2.80") |
| Spesifikasi Produk | Rated Noise Power : 6 W (100 V Line), 3 W (70 V Line) | Rated Impedance ; 100 V line: 1.7 kΩ (6 W), 3.3 kΩ (3 W), 6.7 kΩ (1.5 W), 13 kΩ (0.8 W) ; 70 V line: 1.7 kΩ (3 W), 3.3 kΩ (1.5 W), 6.7 kΩ (0.8 W), 13 kΩ (0.4 W) | Sensitivity : 94 dB (1 W, 1 m) (330 Hz - 3.3 kHz, pink noise) | Frequency Response : 45 Hz - 20 kHz (pink noise -20dB) | Speaker Component : 16 cm (6") cone-type | Dimensions for Fixing Hole ; Mounting hole : φ200 ±3mm ; Ceiling thickness 5-25 mm (0.2"-0.98") | Speaker Mounting Method : Suspension Spring | Applicable Cable ; Solid wire: φ0.5 - φ3.0 mm2 (AWG20-12) | Connection : Push wire connection (bridging terminal 2-branch type) | Finish ; Frame: Steel plate, white (RAL 9016 equivalent), paint ; Grille: Steel net, white (RAL 9016 equivalent), paint | Dimensions : φ200 × 5 (exposed section) + 71 (D) mm (φ7.87" × 0.19" + 2.80") |
